Battery Voltage:
220V 50HZ
|
|
MIG Output current range(A):
40-300A
|
|
LIFT TIG Output current range(A):
15-160A
|
|
MMA Output current range(A):
20-260A
|
|
Duty cycle Т=25С° ( %):
60
|
|
Rated No Volatage:
55
|
|
Insulation class:
H
|
|
Protection class:
IP21S
|
|
Power factor(cosɸ):
0.7
|
|
Efficiency(%):
85
|
|
Wire diameter MIG(mm):
0.6/ 0.8/1.0/1.2mm
|
|
Tungten diameter TIG(mm):
1.6-3.2mm
|
|
Welding rod diameter MMA(mm):
1.6-5.0
|
|
Quick joint:
35-50mm
|
